System Model | XS6000G-D24R-G4 |
Processor | Supports 1 or 2 fourth-generation/fifth-generation Intel® Xeon® Scalable processors, with a maximum TDP of 350W |
Chipset | Intel® C741 series server-specific chipset |
GPU Card | Supports up to 8 600W dual-width GPUs |
Memory | 32 DDR5 memory slots, supporting DDR5 4400/4800/5600MHz memory |
Storage Controller | 2 Slimline 4x interfaces (SATA), 2 M.2 2280/22110 sizes (SATA/PCIe 3.0 x1) |
Storage | Supports 24 hot-swappable 2.5” SAS/SATA/NVMe hard drives |
I/O Ports | Front: 2 USB 3.0 ports, 1 VGA port
Rear: 1 serial port, 2 USB 3.0 ports, 1 VGA port, 1 RJ45 management port (optional upgrade with 2 additional 10G RJ45 network ports) |
PCIe Expansion | Up to 15 PCIe 5.0 expansion slots + 1 OCP 3.0 slot |
Power Supply | 3+1 or 2+2 redundancy (2000W/2200W/2600W/3200W) |
Fan | Standard 12 x 6056 hot-swappable N+1 redundant fans |
Management | 1 dedicated RJ45 management network port |
Security | Supports TPM 2.0 module, chassis intrusion alarm, BMC/BIOS redundancy |
Operating System | Microsoft Windows Server, RedHat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu, VMware ESXi, etc. |
Server Size | 176.5mm (H) x 444mm (W) x 850mm (D) |
Working Temperature | Operating Temperature: 5ºC - 35ºC (without direct sunlight) Storage Temperature: -40ºC - 70ºC |
