System Model | XS8000G-D12R-G4 |
Processor | Supports 1 or 2 4th/5th Gen Intel® Xeon® Scalable Processors, with TDP up to 350W |
Chipset | Intel® C741 Series Server-Specific Chipset |
GPU Card | Supports up to 8 GPUs with 600W power, accommodating dual-width, triple-width, and 3.5-width GPUs, maximum GPU width of 70.1mm |
Memory | 32 DDR5 memory slots, supporting DDR5 4400/4800/5600MHz |
Storage Controller | 2 Slimline 4x ports (SATA), 2 M.2 slots (SATA/PCIe3.0x1) for 2280/22110 sizes |
Storage | 12 hot-swappable 3.5"/2.5" SAS/SATA/NVMe drives |
I/O Ports | Front Ports: 12 hot-swappable 3.5"/2.5" SAS/SATA/NVMe hard drives
Rear Ports: 1 serial port, 2 USB 3.0 ports, 1 VGA, 1 RJ45 management port (optional addition of 2*10G RJ45 service ports) |
PCIe Expansion | Up to 13 PCIe expansion slots |
Power Supply | Supports CRPS 2000W/2200W/2600W/3200W power modules, with hot-swap capability and 3+1 redundancy |
Fan | Standard configuration includes 12 hot-swappable 6056 fans and 4 hot-swappable 8038 fans |
Management | 1 dedicated RJ45 management port |
Security | Supports TPM 2.0 module, chassis intrusion alarm, BMC/BIOS redundancy |
Operating System | Microsoft Windows Server, RedHat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu, VMware ESXi etc. |
Server Size | 265mm (H) x 447mm (W) x 910mm (D) |
Working Temperature | Operating Temperature: 5ºC - 35ºC (without direct sunlight); Storage Temperature: -40ºC - 70ºC |
